Auto Drain Valve, For High Pressure, 1/2"
Login To See Price
Out of stock
SKU
S439606
- What machine we are using : ELHD,2KD 7,3G 7
- Brand of machine: GEM
- Model number of the machine : ELHD 004,2KD7 004,2KD7 006,2KD7 008,2KD7 010,2KD7 015,2KD7 020,2KD7 025,2KD7 030,2KD7 040,2KD7 050,2KD7 100,2KD7 075,2KD7 125
- Item part number: ELHD 004,2KD7 004,2KD7 006,2KD7 008,2KD7 010,2KD7 015,2KD7 020,2KD7 025,2KD7 030,2KD7 040,2KD7 050,2KD7 100,2KD7 075,2KD7 125
- Usage:Automatic Drainage, Preventing Water Accumulation, Condensation removal
- Other Brand name if any:
| Valve type | Orifice | Working Pressure | Flow Factor (Kv) | Body&Internals | Media | Insulation/Protection | Seals | Dimensions | Connection | Electrical Spec |
| 20126V01-2X2, DA, NC S0V | 1.2mm | 0-100 Bar | 0.7 LPM | Aluminium/ Standard | Air | Class "P"/IP 67 | S8-PTFE+VITON | 94X50X102mm(LxWxH) | Port Connection : 4G-1/2" BSP(F) | Voltage : 230V(176V to 264V) Frequency : 50 Hz Power : 13 Watts |
